Description
Features
• Field reversible handing for easy installation
• Range of functions and options for a wide variety of commercial applications
• Available in one knob and five finishes
Benefits
• Versatile: Field reversible handing and other product options offer flexibility in many commercial applications
• Economical: Priced affordably to suit projects of all budgets
• Strong & Reliable: ANSI/BHMA Grade 2 certified for long life and reliability
Specifications
- Door Prep ANSI/SDI A250 14
- Door Thickness Adjustable for doors 1-3/8″ to 1-3/4″ (35mm to 44mm)
- Backset 2-3/4″ (70mm) standard, 2-3/8″ (60mm) optional (Specify in comments if needed)
- Handing Non-handed, field reversible
- Latch-bolt 2-3/4″ (70mm) backset, 1/2″ (13mm) throw latch-bolt plain or deadlocking
- Strike ANSI strike 4-7/8″ x 1-1/4″ x 1-1/4″(124mm x 32mm x 32mm) lip to center
- ANSI/BHMA Certified Grade 2, ANSI/BHMA A156.2, Series 4000
- UL/cUL Listed for 3 hour fire doors
- Warranty: 3 years
Certifications
-
ANSI/BHMA A156.36, Grade 2
-
UL-cUL Listed
