Description
Accentra 4601LN Passage Lockset – AU-4601LN, MO-4601LN, PB-4601LN, TB-4601LN, UB-4601LN | ANSI F75 Grade 2 Commercial
The Accentra 4601LN Passage Lockset (ANSI F75) is a Grade 2 commercial passage lever designed for doors that do not require locking, such as corridors, closets, and interior passageways. It is available in the following lever trims:
- AU-4601LN – Augusta
- MO-4601LN – Monroe
- PB-4601LN – Pacific Beach
- TB-4601LN – Hudson
- UB-4601LN – Hudson
Both levers operate the latchbolt at all times, ensuring smooth operation from either side, with ADA-compliant accessibility and field-reversible handing for easy installation.
Lever Options
- Standard Series
- AU – Augusta, MO – Monroe, PB – Pacific Beach
- Reflections Series
- TB – Hudson Lever, UB – Hudson Lever
Available Lever Trims:
- AU-4601LN (Augusta)
- MO-4601LN (Monroe)
- PB-4601LN (Pacific Beach)
- TB-4601LN (Hudson)
- UB-4601LN (Hudson)
Key Features
- Function: Passage / Closet – ANSI Function No. F75
- Operation: Either lever operates the latchbolt at all times (non-locking)
- Handing: Field reversible for easy installation
- Applications: Suitable for commercial, institutional, and multi-use facilities
- Available Options: 5 trims and 6 finishes for design flexibility
- ADA Compliant: Accessible lever design for universal usability
- UL/cUL Fire Rated: Up to 3 hours for added safety
- Windstorm Certified: Meets stringent local building codes
- Warranty: Backed by a 3-year mechanical warranty
Benefits
- Flexible installation with field reversible handing
- Affordable and durable, ideal for projects of any budget
- Meets multiple safety and performance certifications
- Designed for ease of use, accessibility, and commercial-grade reliability
Specifications
- ANSI/BHMA Code: A156.2, Series 4000LN, Grade 2
- Backset Depth (Standard): 2-3/4″
- Backset Range: 2-3/8″ to 2-3/4″
- Latchbolt Throw: 1/2″
- Door Thickness (Standard): 1-3/4″
- Door Thickness Range: 1-3/8″ to 1-3/4″
- Cylinder Format: Conventional, Small Format
- Cylinder Pins: 6 pin
- Number of Keys: 2
- Strike Type: ANSI Curved Lip
- Handing: Non-handed (Field Reversible)
- UL/ULC Listed: Yes
Certifications
- ANSI/SDI 250.13 Certified
- ASTM E1886 / E1996 / E330 Certified
- Florida Building Code Approved (FL# 3063)
- UL/cUL Fire Rated – Up to 3 Hours
- NFPA 80 Compliant
- TAS 201, TAS 202, TAS 203 Certified
- ICC A117.1 & ADA Compliant
