Description

Accentra 2100 Rim Exit Device

The Accentra 2100 Rim Exit Device is a reliable and versatile solution for secure door exits. It can be installed on single doors or pairs of doors made of metal, wood, or composite materials. Additionally, it is designed for wide stile doors and can be paired with various trims to suit many applications.

Key Features:

• Certified for safety: UL/cUL Listed for panic (FVSR/FVSR7) and fire exit (GXHX/GXHX7) applications, with up to a 3-hour fire rating.
• Easy to install: Non-handed design works on both single and paired doors (mullion required for pairs).
• Secure and durable: Steel interlock “E” bracket maintains proper door-to-mullion alignment in fire-labeled devices.
• Reliable operation: Deadlocking pullman latchbolt engages the roller strike for consistent performance.
• Optional features: Hurricane-resistant model available (2100(F)WS) and multiple trim options to match door hardware.
• Standards compliant: Meets ANSI/BHMA A156.3 Type 1, Grade 1 requirements.
• Convenient use: Hex key dogging supplied standard on panic devices.

Applications:

• Single swing doors and pairs of doors (mullion required for pairs)
• Metal, wood, or composite doors
• Standard door thickness 1-3/4″ (optional up to 3-1/2″)
• Door widths: 30″–36″, 36″–42″, 42″–48″

Specifications:

• Minimum stile width: 4-1/2″ (114mm)
• Projection: 2-1/2″ active, 1-3/4″ depressed
• Latchbolt: 3/4″ (19mm) deadlocking stainless steel pullman-type
• Strikes: 757F, 793 optional for double door panic applications
• Fasteners: Machine screws and wood door fasteners standard; sex nuts and bolts for fire exit hardware

Warranty:

• 3-year limited warranty

Options:

• Shim kit #223, sex nuts and bolts, MicroShield® coating for enhanced durability
