Description

Accentra Nextouch NTM613-NR Pushbutton Cylinder – No Deadbolt

The Accentra Nextouch NTM613-NR Pushbutton Mortise Lock delivers Grade 1 commercial security with a mechanical key override and pushbutton access. It is ideal for doors that require key access but do not need a deadbolt. The lock features a deadlocking latchbolt that retracts by lever on either side, except when the outside lever is locked. Additionally, the latchbolt can be operated by key from the outside when the lever is locked, providing extra security.

In addition, the lock is field reversible, UL/ULC listed, and works with ACCENTRA® Reflections® decorative levers and finishes, allowing flexible installation and a professional look.

Key Features

• Function: Sectional mortise lock with pushbutton keypad, no deadbolt
• Operation: Latchbolt retracts by lever on either side; outside lever operates latchbolt with key when locked
• Construction: Heavy-duty mortise design for reliable commercial use
• Accessibility: Anti-panic lever retracts latchbolt from inside while outside lever stays locked
• Warranty: 3-year limited mechanical & electrical; 1-year limited finish
• Applications: Commercial doors that need mechanical key override without deadbolt
• Power Source: 4 AA alkaline batteries (included); optional 9VDC hardwire input with keypad battery backup

Benefits

• Provides ANSI/BHMA Grade 1 security for commercial doors
• Integrates easily with ACCENTRA® Reflections® decorative levers
• Field-reversible handing allows flexible installation
• Deadlocking latchbolt ensures reliable security

Specifications

• ANSI/BHMA Code: A156.13
• ANSI/BHMA Series: Series 1000
• Backset (Standard): 2-3/4″
• Door Thickness: 1-3/4″ min to 2-1/4″ max
• Cylinder Format: Large Format, Small Format, Conventional
• Latchbolt Throw: 3/4″
• Handing: Field reversible
• UL/ULC Listed: Yes
• Deadbolt Operation: Key outside, thumbturn inside
• Anti-Panic Operation: Yes
• Finishes & Styles: Compatible with ACCENTRA® Reflections® decorative levers
• Configuration Requirement: Must be configured by a certified ACCENTRA® integrator

Certifications

• ANSI/BHMA A156.13, Series 1000, Grade 1
• UL Listed
• ULC Listed
• Windstorm Certified (refer to local codes)
