Description

Emtek Classic Top Mount Hanger

The Emtek Classic Top Mount Hanger delivers timeless style and dependable function for sliding barn doors. Featuring a clean top-mount design, this hanger attaches directly to the top of the door for a sleek, unobtrusive appearance that complements both rustic and modern interiors. Made from premium materials and engineered for smooth, quiet movement, it provides the ideal balance of beauty and performance for residential or commercial spaces.

Key Features

• Classic Top-Mount Design – Creates a clean, refined look with no visible face straps.
• Wheel style options: Solid or Spoked
• Fastener style choices:
  • Flat – Hanger or Track
  • Classic – Hanger or Track
• Durable finishes: Oil Rubbed Bronze, Flat Black or Brushed Stainless Steel
• Maximum door weight: 400 lbs (ensure wall structure can support this requirement)

Track Length Options

Available in: 5′, 6′-6″, 8′, 10′, 13′, and 16′

• Longer lengths (10′, 13′, and 16′) include two track pieces connected with a splice for clean, seamless installation.

Kit Includes

• 1 Pair of Hangers with Wheels
• Track Stops
• Fasteners
• Anti-Jump Mechanism
• Floor Guide

Additional Options

• Double Door (DD) Application: Additional hanger kit available
• Soft Open/Close Kit (Optional):
  • Must order two kits for both soft open and soft close functionality
  • Enhances motion control and reduces noise

Installation Notes

• Ensure the mounting surface or wall structure can support up to 400 lbs.
• Tracks must be securely anchored to solid backing or reinforced framing.
• For 10′, 13′, and 16′ systems, the included splice must be installed at the center connection point to maintain alignment and smooth door travel.
• Confirm door thickness and wheel clearance before installation.
