Accentra AU-426F Escutcheon Lever Trim Exit Device

Assa Abloy Accentra

Assa Abloy Accentra a leading brand of commercial hardware, formerly known as Yale Commercial, has been rebranded but using the same great quality products!

Manufacturers Website

Accentra AU-426F Escutcheon Lever Trim Exit Device

Price range: $169.50 through $275.63

Secure Lever Access

Deliver controlled entry with a durable escutcheon lever trim designed for classroom and storeroom applications. Built for high-traffic use, it provides reliable performance with compatible exit devices.

Please include any comments we should know about your order.

Description

Accentra AU-426F Escutcheon Lever Trim Exit Device

The Accentra AU-426F Escutcheon Lever Trim provides secure and durable access control for exit device applications requiring classroom or storeroom functionality (ANSI 08/09). Designed for use with Accentra rim exit devices, this trim delivers reliable performance in high-traffic commercial and institutional environments.

Part of the 420F Series, the trim features a strong cast zinc escutcheon and through-bolts directly to the exit device for added strength and long-term durability. Certified to ANSI/BHMA A156.3 Grade 1, it meets rigorous standards for safety and performance.

The Accentra 426F fits standard 1-3/4″ (44mm) doors, with options available for doors up to 2-1/4″ (57mm) or shim-mounted devices when specified at the time of order. It is available only with AU, MO, or PB lever designs and supports a range of architectural finishes to match commercial hardware packages.

A rim cylinder is required for operation and is sold separately.

Key Features
  • Function: Classroom or Storeroom (ANSI 08/09)
  • Certification: ANSI/BHMA A156.3 Grade 1
  • Construction: Strong cast zinc escutcheon
  • Mounting: Through-bolted to exit device for added strength
  • Door Thickness:
    • Standard: 1-3/4″ (44mm)
    • Optional: Up to 2-1/4″ (57mm) or shim-mounted (specify on order)
  • Dimensions: 2-1/2″ x 9-1/2″ x 7/16″ (64mm x 241mm x 11mm)
  • Lever Designs: Augusta Lever
  • Cylinder: Rim cylinder required (sold separately)
  • Finishes: 630, 689, 691, 693, 695
  • Warranty: 1-year limited warranty
Compatibility
  • For use with Accentra 6000, 2100, and 1800 Series exit devices

Additional information

Finish

626 – Satin Chrome, 630 – Satin Stainless Steel, 689 – Aluminum Painted, 691 – Light Bronze Painted, 693 – Black Painted, 695 – Dark Bronze Painted

Cylinder Option

Less Cylinder, 2109 Schlage C Keyway – Masterkeyed, 2109 Schlage C Keyway – Keyed Random, 1109 PARA keyway – Masterkeyed, 1109 PARA keyway – Keyed Random
