Description

Accentra 5403LN Patio Lever (Non-Key)

The Accentra 5403LN Patio Lever is a heavy-duty, non-keyed patio and privacy lever designed for exit doors with limited entry requirements. Featuring a deadlocking latchbolt for enhanced security, either lever operates the latchbolt unless the outside lever is locked using the inside pushbutton. The lock automatically releases when the inside lever is turned or when the door is closed, providing added safety and convenience. The inside lever always remains active to ensure safe and easy exit at all times.

Lever Options

• Standard Series
  • AU – Augusta, MO – Monroe, PB – Pacific Beach

Key Features

• Function: Patio / Privacy (Non-Keyed) – F77A
• Operation:
  • Either lever operates the latchbolt unless locked by inside pushbutton
  • Deadlocking latchbolt for improved security
  • Automatic release when inside lever is turned or door is closed
  • Free-wheeling levers in locked position for added protection
  • Inside lever always active for safe exit
• Construction: Heavy-duty Grade 1 performance for strength and durability
• Accessibility: ADA compliant for ease of use
• Warranty: 7-year mechanical warranty
• Applications: Exit doors with limited entry, patios, and privacy-required doors

Benefits

• Provides secure privacy and controlled access without the use of a key
• Deadlocking latchbolt enhances protection against forced entry
• Automatic unlocking improves safety and ease of egress
• Free-wheeling lever design helps resist vandalism and abuse
• Rugged construction ensures long-term durability in high-traffic areas
• Adjustable rose allows easy installation on various door thicknesses
• Certified ANSI/BHMA Grade 1 for heavy-duty performance
• Ideal for residential and commercial exit and patio applications

Specifications

• Brand: Accentra (Formerly Yale)
• Usage: Heavy Duty
• ANSI/BHMA Standard: A156.2, Series 4000 Grade 1
• Latch: 1/2″ throw – 1-1/8″ x 2-1/4″ face
• Backset: 2-3/4″
• Strike: 4-7/8″ x 1-1/4″ ASA/ANSI with curved lip (ANSI A115.2 prep)
• Handing: Non-Handed
• Door Thickness: 1-3/4″ to 2-1/4″
• ADA Compliance: Meets A117.1 Accessibility Code

Certifications

• ANSI/BHMA Grade 1 certified for heavy-duty commercial use
• Compliant with ANSI A156.2 (Series 4000) and ANSI A156.41 standards
• ADA and ICC A117.1 accessible design compliant
• UL/cUL fire-rated for up to 3 hours
• Florida Building Code approved (FL# 3063)
• NFPA 80 compliant for fire door applications
• Windstorm and impact resistant (ASTM E330, E1886, E1996)
• Certified to TAS 201, TAS 202, and TAS 203 standards
