Description

Accentra 5305LN Storeroom Lever

The Accentra 5305LN Storeroom Lever is ideal for storeroom, utility, and exit doors where secure access is required. It features a deadlocking latchbolt, with the inside lever always active for safe egress while the outside lever remains locked and operable only with a key. Free-wheeling lever handles in the locked position provide added protection against tampering and forced entry.

Lever Options

• Standard Series
  • AU – Augusta, MO – Monroe, PB – Pacific Beach, B AU – Augusta

Key Features

• Function: Storeroom / Closet – F86
• Operation:
  • Deadlocking latchbolt for reliable security
  • Inside lever operates latchbolt for safe exit
  • Outside lever locked at all times; key required for operation
  • Free-wheeling lever handles reduce forced-entry risk
• Construction: Durable Grade 2 performance for everyday use
• Accessibility: ADA-compliant lever for accessible operation
• Warranty: 5-year mechanical warranty
• Applications: Storerooms, utility rooms, and exit doors requiring controlled access

Benefits

• Provides secure access to restricted areas while allowing safe exit
• Deadlocking latchbolt improves resistance to tampering and forced entry
• Free-wheeling lever design adds protection against vandalism
• Durable Grade 2 construction ensures long-lasting performance in high-use areas

Specifications

• ANSI/BHMA Code: A156.2
• Backset (Standard): 2 3/4″
• Optional Backsets: 2 3/8″ min, 6″ max
• Door Thickness: 1 3/8″ min to 2 1/4″ max
• Cylinder Format: Conventional, Large Format, Small Format
• Pins: 6-pin (where applicable)
• Handing: Non-handed
• Latchbolt Throw: 1/2″
• Strike: ANSI Curved Lip
• UL/ULC Listed: Yes

Certifications

• NSI/SDI 250.13
• ASTM E330
• Florida Building Code Approved (FL# 3063)
• ADA Compliant
• UL/cUL Fire-Rated Up to 3 Hours
• ASTM E1996
• ASTM E1886
• NFPA 80 Compliant
• TAS 201 / TAS 202 / TAS 203
• ICC A117.1
• ANSI/BHMA A156.2, Series 4000, Grade 2
• ANSI/BHMA A156.41
