Accentra 5303LN Patio Lever (Non-Key)

The Accentra 5303LN Patio Lever is designed for patio and secondary exit doors where controlled entry and convenient privacy are needed. It features a deadlocking latchbolt for added security and allows either lever to operate the latch unless the inside pushbutton locks the outside lever. The lock automatically releases when the inside lever is turned or the door is closed, ensuring smooth operation and preventing accidental lockouts. The inside lever always remains active for quick and safe egress, while the free-wheeling mechanism helps resist forced entry and vandalism.

Lever Options

• Standard Series
  • AU – Augusta, MO – Monroe, PB – Pacific Beach

Key Features

• Function: Patio / Privacy – F77A
• Operation:
  • Deadlocking latchbolt adds strength and security
  • Either lever operates latchbolt unless locked by inside pushbutton
  • Automatic release when the inside lever is turned or door is closed
  • Inside lever always active for safe exit
  • Free-wheeling lever design helps prevent forced rotation
• Construction: Certified Grade 2 for reliable everyday performance
• Accessibility: ADA-compliant lever for accessible operation
• Warranty: 5-year mechanical warranty
• Applications: Patio doors, secondary exits, privacy areas, and rooms requiring limited outside access

Benefits

• Provides reliable privacy control with quick-release safety features
• Deadlocking latchbolt improves resistance against tampering
• Free-wheeling mechanism adds protection and reduces damage
• Designed for smooth, comfortable operation and long-term durability

Specifications

• ANSI/BHMA Code: A156.2
• Backset (Standard): 2 3/4″
• Optional Backsets: 2 3/8″ min, 6″ max
• Door Thickness: 1 3/8″ min to 2 1/4″ max
• Cylinder Format: Conventional, Large Format, Small Format
• Pins: 6-pin (where applicable)
• Handing: Non-handed
• Latchbolt Throw: 1/2″
• Strike: ANSI Curved Lip
• UL/ULC Listed: Yes

Certifications

• NSI/SDI 250.13
• ASTM E330
• Florida Building Code Approved (FL# 3063)
• ADA Compliant
• UL/cUL Fire-Rated Up to 3 Hours
• ASTM E1996
• ASTM E1886
• NFPA 80 Compliant
• TAS 201 / TAS 202 / TAS 203
• ICC A117.1
• ANSI/BHMA A156.2, Series 4000, Grade 2
• ANSI/BHMA A156.41
