Description
Accentra AU-4707LN Entry Lever | Augusta Lever
The Accentra AU-4707LN Augusta Entry Lever is designed for residential, office, and commercial entrance doors, providing dependable security with smooth, everyday operation. Its versatile design allows either lever to operate the latchbolt, unless the outside lever is locked from the inside, giving users flexible control over access.
Lever Options
- Standard Series – AU – Augusta
Available Lever Trims:
- AU-4707LN x 626 (Satin Chrome)
- AU-4707LN x BSP (Black Suede Powder Coat)
- AU-4707LN x 605 (Bright Brass)
- AU-4707LN x 606 (Satin Brass)
- AU-4707LN x 613E (Dark Oxidized Satin Bronze equivalent)
- AU-4707LN x 625 (Bright Chrome)
- AU-4707LN x 612 (Satin bronze)
- AU-4707LN x 619 (Satin Nickel Plated)
- AU-4707LN x WSP (White Suede Powder Coat)
Key Features
- Function: Entrance / Office – ANSI F109
- Operation:
- Either lever operates latchbolt unless outside lever is locked
- Inside turn button locks outside lever
- Automatic release when inside lever turns or when key rotates outside lever
- Turn button can hold outside lever locked when rotated 90°
- Inside lever always active for safe egress
- Free-wheeling lever prevents damage when locked
- Applications: Entrance doors, offices, general-use doors
- Construction: Grade 1 strength for heavy-duty operation
- Handing: Non-handed for easy installation
Benefits
- Provides flexible locking options for various access needs
- Ensures safe, always-active egress from inside
- Free-wheeling mechanism protects the lock from damage
- Ideal for homes, offices, and commercial facilities
Specifications
- ANSI/BHMA: A156.2, Series 4000, Grade 1
- Backset: 2-3/4″ standard (other options available)
- Cylinder Formats: Conventional, Large Format IC, Small Format IC
- Pins: 6-pin (when keyed cylinder format is used)
- Door Thickness: 1-3/4″ standard (1-3/8″ to 2-1/4″ range)
- Latchbolt Throw: 1/2″
- Strike: ANSI curved lip
- Handing: Non-handed
- Max Backset: 19″
- UL/ULC Listed: Yes, up to 3 hours
- Warranty: 5-year mechanical warranty
Certifications
- ANSI/SDI 250.13
- UL/cUL Fire Rated (Up to 3 Hours)
- ADA Compliant
- NFPA 80
- ASTM E1886, E1996, E330
- Florida Building Code Approved (FL# 3063)
- TAS 201, 202, 203
- ICC A117.1
- ANSI/BHMA A156.2 (Grade 1)
- ANSI/BHMA A156.41
